Sunday, January 15, 2023

Moth orchid - Phalaenopsis in reflected ultraviolet photography and simulated butterfly and bee vision using a UV-Nikkor 105mm lens IV

Today in January 2023 some studio shots of a well known decorative flower, a white Moth orchid - Phalaenopsis in reflected ultraviolet photography using my "work horse" UV filter as well as simulated bee and butterfly vision  shot with my "work horse" UV-Nikkor f4.5/105mm quartz fluorite lens. UV filter used was the Baader-U filter, my "work horse" filter for reflected UV as well as my proprietary XBV filters for simulated bee and butterfly vision. All shots were done at f11. Light source used was a Xenon flash modified for high UV output.

[click on image to see a larger one]

Human Vision (VIS):


Reflected UV (Baader-U):


Simulated Butterfly Vision:


Simulated Bee Vision:


Quadriptych of human vision, UV, simulated bee and butterfly vision (left to right, top to bottom):


This orchid has not a very specific UV pattern, its petals are UV reflective around 380nm, but its middle tip (column and gymnostemium) have a rather UV bright spot reflecting around 370nm surrounded by an UV-dark area which gets nicely visible.

The UV-Nikkor 105mm lens is known to be a very well working one for multispectral imaging w/o focus shift, with a nice 1:2 close up focusing capability from infinity up to 48cm (0.48 meter). Sharpness is very good and so is its contrast, even from f4.5 onwards. With a Nikon PN-11 extension tube of 52.5mm length it reaches 1:1 (1x) magnification. It has the standard Nikon-F mount, and it covers full format sensors (41mm image diameter). It is defined to reach down to 190nm and up to 1300nm in near infrared; my measured transmission spectra of it may be seen here.

I have written more about this orchid HERE

Stay tuned, more will follow on that fascinating subject...

More info on this very interesting field may be found on my site http://www.pbase.com/kds315/uv_photos

Moth orchid - Phalaenopsis in reflected ultraviolet photography and simulated butterfly and bee vision using a UV-Nikkor 105mm lens III

Today in January 2023 some studio shots of a well known decorative flower, a yellow-orange Moth orchid - Phalaenopsis in reflected ultraviolet photography using my "work horse" UV filter as well as simulated bee and butterfly vision  shot with my "work horse" UV-Nikkor f4.5/105mm quartz fluorite lens. UV filter used was the Baader-U filter, my "work horse" filter for reflected UV as well as my proprietary XBV filters for simulated bee and butterfly vision. All shots were done at f11. Light source used was a Xenon flash modified for high UV output.

[click on image to see a larger one]

Human Vision (VIS):


Reflected UV (Baader-U):


Simulated Butterfly Vision:


Simulated Bee Vision:


Quadriptych of human vision, UV, simulated bee and butterfly vision (left to right, top to bottom):


This orchid has not a very specific UV pattern, its petals are UV reflective around 380nm, but its middle tip (column and gymnostemium) have a rather UV bright spot reflecting around 370nm surrounded by an UV-dark area which gets nicely visible.

The UV-Nikkor 105mm lens is known to be a very well working one for multispectral imaging w/o focus shift, with a nice 1:2 close up focusing capability from infinity up to 48cm (0.48 meter). Sharpness is very good and so is its contrast, even from f4.5 onwards. With a Nikon PN-11 extension tube of 52.5mm length it reaches 1:1 (1x) magnification. It has the standard Nikon-F mount, and it covers full format sensors (41mm image diameter). It is defined to reach down to 190nm and up to 1300nm in near infrared; my measured transmission spectra of it may be seen here.

I have written more about this orchid HERE

Stay tuned, more will follow on that fascinating subject...

More info on this very interesting field may be found on my site http://www.pbase.com/kds315/uv_photos

Wednesday, January 11, 2023

Winter Jasmine - Jasminum Nudiflorum in reflected ultraviolet photography and simulated bee and butterfly vision VI

Today in 2023 shots of a beautiful winter flower, a Winter Jasmine - Jasminum nudiflorum in reflected ultraviolet photography using my "work horse" UV filter, the Baader-U filter, as well as in simulated bee and butterfly vision using my propriatary XBV filters. All shots were done at f11. Lens was a UV-Nikkor 105mm quartz fluorite lens. Light source was a modified Xenon flash.

[click on image to see a larger one]

Human vision:


Reflected ultraviolet (UV):


Simulated bee vision:


Simulated butterfly vision:


Quadriptych of human vision, ultraviolet, simulated bee and butterfly vision (left to right, top to bottom):


This flower shows a very prominent and strong UV reflection around 365nm on its petals, but its center is UV-dark, and all this gets nicely visible, also in simulated bee and butterfly vision.

Stay tuned, more will follow on that fascinating subject...


I have previously written about this flower HERE

More info on this very interesting field may be found on my site http://www.pbase.com/kds315/uv_photos
